| Place of Origin: | Shenzhen, China |
|---|---|
| Brand Name: | J&R |
| Certification: | CE, FCC, RoHS, IP67, ISO9001:2015 |
| Model Number: | JR104-2B |
| Minimum Order Quantity: | 1 unit |
| Price: | Reconsideration |
| Packaging Details: | pearl cotton, carton |
| Delivery Time: | 3-7 working days |
| Payment Terms: | L/C, T/T |
| Supply Ability: | 3000 sets per month |
| Material: | Aluminum Alloy | Weather Resistant: | IP67 |
|---|---|---|---|
| Color: | Yellow, Blue, Red, Orange (or Optional) | Version: | Analogue, SIP/VoIP, GSM/3G |
| Installation: | Wall/ Pillar Mounting | Warranty: | 2 Years |
| Net Weight: | 5 KG | Hearing-Aid: | YES |
| Vandal Resistant: | Yes | Function: | SOS |
| Highlight: | weather resistant telephone,weatherproof telephone box |
||
FEATURE
J&R Costomized Public Weatherproof Emergency SOS intercom telephony
l Standard Analogue phone
l Weather proof protection to IP67
l LED light for incoming call, no need external power supply
l Wall mounting or Pole mounitng, Simple installation
l Inductive coupler fitted as standard for hard of hearing
l Phone line powered
l CE,FCC,ROHS,ISO9001 compliant
Application
J&R Costomized Public Weatherproof Emergency SOS intercom telephony
Metro, Railway, Highway side, Marine, Mining, Tunnels, Steel Plant,Chemical plant,Power plant and related industrial application, etc.
Technical Specification
J&R Costomized Public Weatherproof Emergency SOS intercom telephony
| Analogue Version | ||
| Power Supply | From the analogue telephone network | |
| Supply Voltage | 24 VDC to 65 VDC | |
| Supply Current | 20 mA DC to 100 mA DC | |
| Ringer Volume | - 80dB(A) at a distance of 1 m - 110dB(A) at a distance of 1 m (for external horn speaker) |
|
| Dialing Method | DTMF mode in accordance with ITU-T recommendation Q.23. | |
| Ambient conditions | ||
| Protection type | IP 66 as per EN60529 | |
| Operating temperature | -40°C to +70°C | |
| Storage temperature | -40°C to +85°C | |
Package
J&R Costomized Public Weatherproof Emergency SOS intercom telephony
Certificate
10 Reasons to Choose J&R
1. Where environmental factors pose a problem for conventional telephones
2. Where emergency communication points are needed
3. Where public information points are needed
4. When reliability and up-time are critical goals
5. When central management and control are important
6. Where maintenance access is difficult
7. When compatibility to existing systems is important
8. When voice sound quality is important
9. When future-proofing is needed
10. When ease of installation is important Service – Here when you Need us At J&R, we strive to deliver excellent service and customer support. We offer accreditation and installation training to our authorised partners, imparting best practice when it comes to installation and maintenance support. We also offer extended warranties and repair services on all our deliveries. We aim to respond to all product support requests within 24 hours.
